Ventrac 4500P - Safety Decal Descriptions (Part 2)

SAFETY
Safety - 20
1. Warning - 20 degree maximum slope rating when equipped with
single wheels.
2. Warning - 25 degree maximum slope rating when equipped with 7.6
cm (3 inch) wheel extensions.
3. Warning - 30 degree maximum slope rating when equipped with dual
wheels.
4. Slope rating may be reduced when adding a cab and other accessories
or attachments. Read the operator’s manual for the cab, accessory, or
attachment being used.
5. Reduce speed on slopes, especially when turning. Avoid sharp turns
when operating on slopes.
6. Use low range when operating on slopes. Do not shift between high
and low range on a slope.
7. Torque the wheel lug nuts to 75 Nm (55 ft-lbs).
8. Torque the dual wheel hub draw bolts to 163 Nm (120 ft-lbs).
9. Inate All Terrain tires to the pressure range indicated for single
wheels and the inner and outer dual wheels.
10. Inate Bar tires to the pressure range indicated for single wheels and
the inner and outer dual wheels.
11. Inate Turf tires to the pressure range indicated for single wheels and
the inner and outer dual wheels.
1. Warning - Read the operator’s manual.
G
1
1. Pinching or crushing hazard - foot. Stay away from
moving parts.
1
1. Severing of ngers or hand - engine fan. Stay away
from moving parts.
1
4
5
6
7
8
9
10
11
2 3
1
F
H
E
