SERVICE
Service - 57
Removing the Battery
1. Tilt the seat forward and fasten in place with the
seat prop.
A
2. Remove the left
foot platform
panel (A).
3. Disconnect the
negative (-) bat-
tery cable (B).
4. Disconnect the
positive (+) bat-
tery cable (C).
5.
B
C
D
Remove the battery retainer (D).
6. Slide the battery forward out of the battery com-
partment.
Installing the Battery
1. Slide the battery into the battery compartment
with the negative (-) post to the rear.
2. Install the battery retainer and torque the bolt to
24 Nm (210 in-lbs).
3. Install the left foot platform panel and torque the
bolt to 11 Nm (100 in-lbs).
4. Connect the positive (+) battery cable to the posi-
tive battery post rst.
5. Connect the negative (-) battery cable to the nega-
tive battery post last.
6. Apply dielectric grease to the battery terminals to
prevent corrosion.
7. Place the covers back over the battery terminals.
Cleaning the Battery and Terminals
1. Remove the battery from the power unit.
2. Wash the battery with a solution of 60 mL (4 table-
spoons) of baking soda to 3.8 liters (1 gallon) of
water. Do not allow the soda solution to get into
the battery cells.
3. Rinse the battery with clean water.
4. Clean the battery posts and battery cable termi-
nals with a wire brush.
5. Reinstall the battery.
Charging the Battery
DANGER
Batteries produce explosive gases. Charge the
battery in a well ventilated area where the gases
produced by charging can dissipate. Do not charge
where the battery could be exposed to sparks, open
ames, or other sources of ignition.
Never charge a frozen battery, as it may explode.
Allow the battery to warm up and inspect for cracks
or damage before charging.
To preserve optimum battery performance and life,
do not allow the battery to stand in a discharged state
for long periods of time. If the battery is not being
used, check the battery voltage every 30 days and
recharge the battery if the voltage drops to 12.4 volts
or lower.
Keep the battery fully charged in cold weather to pre-
vent damage due to freezing.
1. If possible, remove the battery from the power
unit before charging.
2. Refer to the battery charger’s manual for specic
charging instructions.
3. If electrolyte is expelled or excessive gassing oc-
curs, or if the temperature of the battery exceeds
52° C (125° F), charging must be temporarily
stopped to permit cooling. After cooling, reduce
the charging rate before starting the charger
again.
