Ventrac 4500P - High;Low Shift Lever (N); Weight Transfer Traction Control Select Lever (O)

OPERATIONAL CONTROLS
Operation - 27

ATTENTION
The high/low range shift lever shifts both the front
and rear transaxles simultaneously. Occasionally,
the engagement of the transaxle gears is prevented
by misalignment. Moving the steering wheel slightly
to the right or left will move the gears enough to
complete the engagement.
CAUTION
Never shift while under load, while moving, or while
on a slope. Always ensure the shift lever is secured
in the lock position at the end of each shift stroke.
Always install the ball pin to prevent the shift lever
from accidentally moving to the neutral position.
With the power unit parked on level ground,
0
1
2
remove the ball pin (A) and push the shift
lever forward to select low range (1).
Move the shift lever to the middle of the
shift stroke to place the transaxle gears in
neutral (0).
Pull the shift lever back toward the opera-
tor to select high range (2).
A
Ensure the shift
lever is secured in
the lock position at
the end of the shift
stroke. Reinstall the
ball pin (A) into the shift select
bracket position at the same
end as the shift lever, in order
to prevent the shift lever from
being accidentally disengaged.
Weight Transfer Traction Control Select
Lever (O)
The weight transfer system transfers weight
from the attachment to the front wheels of
the power unit. Transferring weight from the
attachment to the power unit increases the
traction control, improves hillside maneuver-
ability, aids in lifting the attachment, reduces
the steering eort, and lessens the attach-
ment resistance when in contact with the
ground.
The operator can select dierent transfer
rates by selecting one of the ve positions
from no weight transfer (0) to maximum
weight transfer (4). Set the weight transfer to 0 when
attaching or detaching any attachment.
