LOGGING OPTIONS
OS Logging Support
66 E355/E265 USER AND BEST PRACTICES GUIDE
• Set *DEBUG=1 or 4 in Edit parameters menu and restart e355 unit.
Figure 38 Debug Port and COM1 Port
*LOG (File Based)
• Log data will be written to a circular buffer, which is stored in file in flash
memory.
• *LOG specifies the size in kb, the allowable range is between 50 and 32 x
1024 kb.
• Log data will include an OS timestamp. When examining timing related issues,
this is much more informative than a time stamp generated on a PC receiving
a log.
• To upload the logs, Press Backspace + 4 key simultaneously on VTM menu 1,
or password prompt screen. The log will be uploaded to the device specified
by *LOGP, values 1 and U are supported (1 for COM1 port and U for USB
device port).
• Incremental logs can be obtained by going to the password prompt screen,
uploading the log, and then cancelling VTM password entry prompt. This
upload technique avoids a system restart (entering into VTM menu 1 causes a
system restart).
• Hardware interrupts are disabled during the writing of log in circular buffer,
overhead of *LOG is much less compared to the overhead of *DEBUG.
• Control command G31 with parameter 01O (character 'O' at the end) enables
the *LOG logging with size set to 1024 (1MB) and *LOGP value to 1.
• Control command G32 with parameter O retrieves the log one record at a time
until the log is empty.
U
A
R
T
U
S
B
R
TS
(
R
S
2
3
2
)
M
I
C
R
O
U
S
B
Debug Port
COM1 Port
It is recommended to disable *DEBUG or *LOG system configuration variables
after completion of problem trouble shooting or evaluating the software.
