SETUP
Installing or Replacing MSAM, Micro SD and SIM Cards
V200
T INSTALLATION GUIDE 17
Changing or
Installing MSAMs
To change or install MSAM cards:
1 Use steps 1 to 3 of Opening Card Compartment to get to the MSAM
cardholder.
2 Remove the old card, if any, and insert the MSAM card carefully into the slot
(with the gold contacts facing downward) until fully inserted.
Figure 6 Inserting MSAM Card
3 If you are finished replacing or inserting cards, replace the battery and lock the
rear cover back in place.
Changing or
Installing Micro SD
Card
To change or install Micro SD cards:
1 Use steps 1 to 3 of Opening Card Compartment to get to the Micro SD
cardholder.
2 Remove the old card, if any, and insert the Micro SD card carefully into the slot
(with the gold contacts facing downward) until fully inserted.
Figure 7 Inserting Micro SD Card
3!-
3)- 3)-
3$
3!-
3!-
3!-
NOTE
Insert the card with the card’s gold contacts facing away from you, toward the unit.
Take note of the notched edge on the MSAM card for quick orientation.
3$
3)- 3)-
3$
3!-
3!-
3$
NOTE
Insert the card with the card’s gold contacts facing away from you, toward the unit.
