SETUP
Smart Card Reader
24 V200T INSTALLATION GUIDE
Smart Card
Reader
The smart card transaction procedure can vary depending on the application.
Verify the proper procedure with your application provider before performing a
smart card transaction.
Figure 16 Using the Smart Card Reader
Conducting a Smart
Card Transaction
To conduct a smart card transaction:
1 Position the smart card with the gold contacts facing upward.
2 Insert the card into the smart card reader slot in a smooth, continuous motion
until it seats firmly.
3 Remove the card when the display indicates the transaction is completed.
Magnetic Stripe
Card Reader Use
The V200t has a magnetic card reader that uses a triple track stripe reader. This
gives the unit greater reliability over a wide range of swipe speeds and operating
environments.
Figure 17 Using the Magnetic Stripe Card Reader
Leave the smart card in the card reader until the transaction is completed.
Premature removal can void the transaction.
