VeriFone VX 520 Instruction Manual

ITCARD • Planet Cash • Planet Pay • Planet Plus
19
In order to make the Sales transaction (the exemplary PIN card transaction procedure):
FIGURE 19 THE SALES TRANSACTION WITH PIN CARD –STANDARD PROCESS
Depending on the application settings, when the card is inserted, the cash withdrawal proposition can be
also displayed on the terminal [see: Promoted Cash Back – description and procedure
]. In such a case the
transaction should be continued according to the Client’s decision.
The dynamic currency conversion (DCC) service is available for the Sales transaction. The DCC transaction
is carried out in the Client card currency (if it is other than PLN). [see Dynamic currency conversion – DCC
]
1. Enter the amount and
confirm by the ENTER
key
2. Insert the card
3. The application
informs about the read of
the card data
4. The Client should
enter the PIN code and
press ENTER
5. The application displays the screens informing about the
connection with the Authorisation Centre
7. The application displays the question about the printout
of the copy for the Client.
ENTER – printout of copy, CANCEL – omission of printout.
8. Remove the card
6. The application displays the result of the transaction and
prints out the confirmation of the completion of the
transaction

VeriFone VX 520 Specifications

General

Processor	400 MHz ARM11
Card Readers	Magnetic stripe, EMV chip
Operating Temperature	0°C to 50°C (32°F to 122°F)
Display	128x64 pixel backlit LCD
Connectivity	Dial-up, Ethernet
Contactless	Optional
Printer	18 lines per second
Security	PCI PTS 3.0 approved
Weight	500g
Dimensions	203 mm x 87 mm x 77 mm (8.0 in x 3.4 in x 3.0 in)
