VeriFone VX 520 Instruction Manual

ITCARD • Planet Cash • Planet Pay • Planet Plus
26
In order to make the Preauthorisation:
FIGURE 29 PREAUTHORIZATION WITH PIN – STANDARD PROCEDURE
FIGURE 31 PREAUTHORIZATION– EXEMPLARY CONFIRMATION PRINTOUTS
Depending on the application settings the Preauthorisation can be performed also without the physical presence
of the payment card, only with the use of the data of the card made available by the Client (e.g. on the basis of
the data given by telephone). In such a case the Seller manually enters the required data – card number, card
expiry date (located on the card reverse) and CVV2/CVC2 code (located on the card reverse).
1. Press the WIĘCEJ
(eng. MORE) key on the
main screen
2. Select
PREAUTORYZACJA (eng.
PREAUTHORISATION) from
the list of transactions
3. Enter the amount and
confirm by the ENTER
key
5. The Client should
enter the PIN code and
press ENTER
8. The application
displays the question
about the printout of the
copy for the Client.
ENTER – printout of
copy; CANCEL –
omission of printout.
9. Remove the card (if it
is left in the chip card
reader).
6. The application
establishes a
connection, displays the
result and makes a
printout
4. Insert the contact
(strip or chip) card
PREAUTHORISATION PRINTOUT
The Seller’s copy
PREAUTHORISATION PRINTOUT
The Client’s copy

VeriFone VX 520 Specifications

General

Processor	400 MHz ARM11
Card Readers	Magnetic stripe, EMV chip
Operating Temperature	0°C to 50°C (32°F to 122°F)
Display	128x64 pixel backlit LCD
Connectivity	Dial-up, Ethernet
Contactless	Optional
Printer	18 lines per second
Security	PCI PTS 3.0 approved
Weight	500g
Dimensions	203 mm x 87 mm x 77 mm (8.0 in x 3.4 in x 3.0 in)
