VeriFone VX805 CTLS User Manual

24
VX 805 CTLS INSTALLATION G UIDE
S ETUP
Optional Accessories
Optional
Accessories
These accessories can be used to further enhance the device’s functionality. See
Supplementary Hardware for additional information.
Using the Privacy
Shield
The privacy shield is used to hide the keys a user is pressing to enter the
password for a transaction.
Installing the
Privacy
Shield
1 Align the hooks on the privacy shield with the corresponding slots beside the
keypad on the VX805 CTLS.
2 Once the hooks are in place, gently push down on the privacy shield until it
snaps into place.
The figure below shows an example of a VX805 CTLS with the privacy shield
installed.
Picture of VX 805 CTLS
Figure 20 Installed Privacy Shield

VeriFone VX805 CTLS Specifications

General

Processor	400 MHz ARM11
Display	128 x 64 pixel LCD with backlight
Connectivity	RS-232, USB
Card Readers	Contactless
Security	PCI PTS approved
Operating Temperature	0°C to 50°C (32°F to 122°F)
Power Supply	12V DC
Weight	295g
