20
VX 805 CTLS INSTALLATION G
UIDE
S
ETUP
Power Supply
Power Supply
Not all VX805 CTLS configurations and device contexts require the use of
a power
supply – VeriFone ships power supplies with the VX805 CTLS as required.
If you have changed the context in which the VX805 CTLS is used or have
questions about which power supply should be used, contact your VeriFone
representative. For more information, see Accessories and Documentation.
CAUTION Using an incorrectly rated power supply can damage the unit or cause it not to
work properly. Use only a power pack with VPN PWR282-001-01-A (see
Specifications for detailed power supply specifications).
Before connecting a power supply, disconnect the power pack cord from the
power outlet.
Connect and route all cables between the VX805 CTLS and the ECR or PC
before plugging the power pack cord into a wall outlet or surge protector.
WARNING
Do not plug the power pack into an outdoor outlet or operate the VX805 CTLS
outdoors. Also, disconnecting power during a transaction can cause transaction
data files not yet stored in memory to be lost.
NOTE
To protect against possible damage caused by lightning strikes and electrical
surges, VeriFone recommends installing a power surge protector.
When the VX805 CTLS has power and an application is loaded, the application
starts after the initial VeriFone copyright screen and displays a unique copyright
screen. If no application is loaded,
DOWNLOAD NEEDED appears on the display
after the initial VeriFone copyright screen.
Power Connections
For power connections, connect the VX805 CTLS to any of the following power
sources:
• Connecting to External Power Using Junction Box
• Connecting to External Power Using Serial Power Cable
CAUTION
Using an incorrectly rated power supply can damage the unit or cause it not to
work properly. Use only a power pack with VPN PWR 282-001-01-A (see
Specifications for detailed power supply specifications and Accessories and
Documentation for ordering information).
