PCB with Components CS1929001 16 KEY, IS: OFF

CS1929002 4 KEY, IS: OFF

CS1929003 16 KEY, IS: ON

CS1929004 4 KEY, IS: ON

Printed Circuit Board FR015750B 1-5

Printed Circuit Board FR015750C 6-

C 2002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a1

C 2006 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1

C 2007 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1-5 A E1

C 2007 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 6- A E1

C 2008 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1

C 2009 CHIP TA.CAP. 2.2uF 6.3V TEESVA0J225M8R K78080009 1- A E1

C 2011 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1

C 2013 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D1

C 2014 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 7- A D1

C 2015 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A F4

C 2016 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G2

C 2018 AL.ELECTRO.CAP. 220uF 10V ESMG100ELL221ME11S K40109027 1- B a3

C 2019 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1-5 A G3

C 2019 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 6- A G3

C 2020 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A G3

C 2021 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B a1

C 2022 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2

C 2024 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 1- B a1

C 2025 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a1

C 2026 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 1- B a1

C 2027 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a1

C 2028 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 2029 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B b1

C 2031 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 2032 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B b1

C 2034 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B b1

C 2035 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1

C 2036 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1

C 2037 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1-5 A F1

C 2037 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 6- A F1

C 2038 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 2041 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A D1

C 2042 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A C1

C 2043 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D1

C 2044 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f2

C 2045 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A D1

C 2046 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1-5 B f1

C 2046 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 6- B f1

C 2047 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1-5 A E4

C 2047 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 6- A E4

C 2048 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A E3

C 2050 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1-5 A F3

C 2050 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 6- A F3

C 2052 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A F3

C 2054 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- A F3

C 2055 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A F3

C 2057 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B a1

C 2058 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a2

C 2059 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B b2

C 2060 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B b1

C 2062 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1-4 B b2

C 2062 CHIP TA.CAP. 4.7uF 16V TEESVB21C475M8R K78120016 IS 5- B b2

C 2062 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 NON IS 5- B b2

C 2063 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 2065 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B c1

C 2066 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B c1

C 2068 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 2069 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 2071 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f1

Parts List

DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE LAY ADR

MAIN-2 Unit
