Vertex Standard VX-424A Series User Manual

38
D 2023 DIODE HVD372B KRF-E G2070966 1- B c2
D 2024 DIODE HVD372B KRF-E G2070966 1- B c2
D 2026 DIODE HVD358B KRF-E G2070950 1- B b3
D 2027 LED LNJ808K8SRA G2070790 1- A B1
D 2028 LED LNJ808K8SRA G2070790 16KEY 1- A A1
D 2029 LED LNJ808K8SRA G2070790 1- A B3
D 2030 LED LNJ808K8SRA G2070790 16KEY 1- A A3
D 2031 DIODE 1SS400G T2R G2070934 1- B g2
D 2032 DIODE 1SS400G T2R G2070934 1- B g2
D 2033 DIODE 1SS400G T2R G2070934 1- B g2
D 2034 DIODE 1SS400G T2R G2070934 1- B g2
D 2035 DIODE 1SS400G T2R G2070934 1- A E2
D 2036 DIODE DA221 TL G2070178 1- B c4
D 2037 DIODE HVD358B KRF-E G2070950 1- B c2
D 2038 DIODE HVD358B KRF-E G2070950 1- B c2
D 2039 LED 12-22SURSYGC/S530-A2/TR8 G2070810 1-5 A G1
D 2039 LED LTST-S326KGJRKT G2071172 6- A G1
D 2040 LED TLOU1008A(T04) G2070958 1- A D3
D 2041 DIODE 1SS400G T2R G2070934 1- B f3
D 2042 DIODE 1SS400G T2R G2070934 1- A E3
D 2043 DIODE 1SS400G T2R G2070934 1- B e3
D 2044 DIODE DAN222 TL G2070174 1- B d4
D 2045 DIODE DAN222 TL G2070174 1- B d4
D 2046 DIODE HSC277TRF-E G2070584 1- B d2
D 2047 DIODE 1SS400G T2R G2070934 1- B f4
D 2048 DIODE UDZS TE-17 6.8B G2070888 1- A C1
D 2049 DIODE HSM88AS TR-E G2070170 1- B g2
D 2050 DIODE RB751S-40TE61 G2070850 1- A E2
DS2001 LCD TP5451T00 G6090174 1- A D2
F 2001 CHIP FUSE 3A 0434 003. 3.0A Q0000107 1-3 A G3
F 2001 CHIP FUSE 3A 0434 003. 3.0A Q0000107 IS 4-5 A G3
F 2001 CHIP FUSE 3.15A FHC16 322ADTP Q0000118 NON IS 4-5 A G3
F 2001 CHIP FUSE 3.15A FHC16 322ADTP Q0000118 6- A G3
FB2002 FERRITE BEADS BLM18PG600SN1D L1690601 1- A E4
FB2003 FERRITE BEADS BLM18PG600SN1D L1690601 1- A E3
FB2004 FERRITE BEADS BLM18PG600SN1D L1690601 1- A F4
HS2001 HEATSINK PLATE 1.5t-5-6 RA0736100 1 B c1
HS2001 HEATSINK 1.35t-5-6 RA073610A 2- B c1
J 2001 CONNECTOR HSJ1594-010055 P1090896 1- B b4
J 2002 CONNECTOR AXK6S40535P P0091209 1- B f2
J 2003 CONTACT OG-503040 S5000243 1- A F2
J 2004 CONTACT OG-503040 S5000243 1- A F2
L 2001 M.RFC 0.1uH HK1608 R10J-T L1690528 1- B e1
L 2002 COIL 0.038uH AS050630-38N L0022818 1- B a1
L 2003 COIL 0.038uH AS050630-38N L0022818 1- B a1
L 2004 COIL E2 0.5-2.0-5T-R L0022487 1- B b1
L 2005 M.RFC 0.82uH LK2125 R82K-T L1690318 1- B b2
L 2006 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- A F1
L 2007 COIL E2 0.3-1.7-8T-L L0022376 1- B a1
L 2008 COIL E2 0.3-1.7-8T-L L0022376 1- B a2
L 2009 COIL E2 0.5-1.4-2.5T-L L0022613 1- B b1
L 2010 COIL E2 0.35-1.6-7T-L L0022390 1- B b1
L 2011 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- B c1
L 2012 COIL E2 0.3-1.7-7T-R L0022372 1- B a2
L 2013 COIL E2 0.35-1.6-7T-L L0022390 1- B c1
L 2014 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- B d1
L 2015 COIL E2 0.3-1.7-7T-R L0022372 1- B a2
L 2016 M.RFC 0.1uH HK1608 R10J-T L1690528 1- B a3
L 2017 M.RFC 0.1uH HK1608 R10J-T L1690528 1- B d1
L 2018 M.RFC 0.1uH HK1608 R10J-T L1690528 1- B e2
L 2019 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- B b2
L 2020 COIL E2 0.3-1.7-7T-R L0022372 1- B a3
L 2021 M.RFC 0.1uH HK1608 R10J-T L1690528 1- B d1
L 2022 M.RFC 0.12uH HK1608 R12J-T L1690937 1- B c3
L 2023 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- B c2
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
MAIN-2 Unit
Parts List
