Vertex Standard VX-424A Series User Manual

39
L 2024 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- B c2
L 2025 COIL E2 0.3-1.7-7T-R L0022372 1- B a3
L 2026 CHIP COIL 15uH LQH32MN150K23L L1690089 1- A E3
L 2027 M.RFC 0.068uH HK1608 68NJ-T L1690526 1- B d2
L 2028 M.RFC 0.1uH HK1608 R10J-T L1690528 1- B d2
L 2029 M.RFC 0.39uH 2% C1608CB-R39G-RF L1691107 1- B d2
L 2031 M.RFC 1uH LK1608 1R0K-T L1690687 1- B g2
L 2032 M.RFC 0.082uH HK1608 82NJ-T L1690527 1- B b2
L 2033 M.RFC 0.82uH LK1608 R82K-T L1690417 1- B b2
L 2036 COIL 0.025uH AS030521-25NK L0022585 1- B c2
L 2038 COIL E2 0.35-1.6-5.5T-L L0022616 1- B c2
MC2001 MICROPHONE ELEMENT SKB-2244S-C1033MG M3290040 1-2 A E1
MC2001 MICROPHONE ELEMENT OB-22S44-C1033MG M3290048 3- A E1
P 2001 SPRING CONNECTOR R0152490 1- B a1
Q 2002 TRANSISTOR UMX1N TN G3070324 1- A F1
Q 2003 TRANSISTOR IMZ2A T108 G3070060 1- A F1
Q 2004 TRANSISTOR 2SA1602A-T111-1F G3116028F 1-5 A D1
Q 2004 TRANSISTOR 2SA1576A T106 R G3115768R 6- A D1
Q 2005 IC NJM2070M-TE2 G1092944 1-4 A F3
Q 2005 IC NJM2070M-TE1 G1094509 5- A F3
Q 2006 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 A F3
Q 2006 TRANSISTOR 2SC4081 T106 R G3340818R 6- A F3
Q 2007 TRANSISTOR CPH6102-TL G3070223 1- A F3
Q 2008 FET RD07MVS1A-T12 G3070352 1- A E1
Q 2009 TRANSISTOR 2SA1602A-T111-1F G3116028F 1-5 B f3
Q 2009 TRANSISTOR 2SA1576A T106 R G3115768R 6- B f3
Q 2010 IC LA8630M-B-TLM-E G1093452 1- B e3
Q 2011 FET 2SK3541 T2L G3835417 1- B e3
Q 2012 TRANSISTOR CPH6102-TL G3070223 1- B g3
Q 2013 TRANSISTOR UMX1N TN G3070324 1- B g3
Q 2014 FET RD01MUS1-T113 G3070321 1- B d1
Q 2015 IC M62364FP 600D G1093033 1- B e1
Q 2016 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 B e1
Q 2016 TRANSISTOR 2SC4081 T106 R G3340818R 6- B e1
Q 2017 TRANSISTOR CPH6102-TL G3070223 1- B f3
Q 2018 TRANSISTOR UMX1N TN G3070324 1- B g3
Q 2019 TRANSISTOR 2SC5006-T1 G3350068 1- B a2
Q 2020 TRANSISTOR 2SC5227-4-TB G3352278D 1- B d1
Q 2021 IC AK2342BP G1093143 1- B f1
Q 2022 TRANSISTOR DTB123EK T146 G3070022 1- B f4
Q 2023 IC LMV321IDCKR G1093969 1- B g2
Q 2024 TRANSISTOR UMX1N TN G3070324 1- A G1
Q 2025 IC NJM2871AF35(TAPE) G1093899 1- B f3
Q 2026 TRANSISTOR 2SC5005-T1 G3350058 1- B d2
Q 2027 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 B c2
Q 2027 TRANSISTOR 2SC4081 T106 R G3340818R 6- B c2
Q 2028 TRANSISTOR DTC144EE TL G3070075 1- B d2
Q 2029 FET 3SK320(TE85L) G4803208 1- B b3
Q 2030 FET 2SK210-GR(TE85R.F) G3802107G 1- B c2
Q 2031 TRANSISTOR DTC124TE TL G3070128 1- B d2
Q 2032 TRANSISTOR DTC144EE TL G3070075 1- B d2
Q 2033 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- B d2
Q 2034 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 A D4
Q 2034 TRANSISTOR 2SC4081 T106 R G3340818R 6- A D4
Q 2035 TRANSISTOR DTC114TE TL G3070225 1- A C4
Q 2036 IC BR93L86RFVM-WTR G1094242 1- A E3
Q 2037 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 A E2
Q 2037 TRANSISTOR 2SC4081 T106 R G3340818R 6- A E2
Q 2038 FET 2SK3541 T2L G3835417 1- B f3
Q 2039 TRANSISTOR DTA144EE TL G3070074 1- A F3
Q 2040 IC BD4835FVE-TR G1093967 1- A E3
Q 2041 TRANSISTOR 2SC4215Y(TE85R.F) G3342157Y 1- B c3
Q 2042 IC SA7025DK G1093014 1- B e2
Q 2043 TRANSISTOR UMC5N TR G3070137 1- B e2
Q 2044 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 A G2
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
MAIN-2 Unit
Parts List
