40
Q 2044 TRANSISTOR 2SC4081 T106 R G3340818R 6- A G2
Q 2045 TRANSISTOR 2SC4154-T111-1E G3341548E 1-5 A D4
Q 2045 TRANSISTOR 2SC4081 T106 R G3340818R 6- A D4
Q 2046 TRANSISTOR DTC114TE TL G3070225 1- A D3
Q 2047 IC LC87F7BC8A-F56G2-E G1094209 1- A D2
Q 2048 IC TA31136FNG(EL) G1091605 1- B d3
Q 2049 TRANSISTOR 2SC5226-4-TL G3352268D 1- B e2
Q 2052 TRANSISTOR DTC144EE TL G3070075 1- B e3
Q 2054 IC NJM12904R-TE1 G1093337 1- A F2
Q 2055 FET 2SK3541 T2L G3835417 1- B f1
Q 2056 TRANSISTOR DTC144EE TL G3070075 1- B e4
Q 2057 IC TC7W74FU(TE12L,F) G1091788 1- B g3
Q 2058 TRANSISTOR CPH6102-TL G3070223 1- B g3
Q 2059 TRANSISTOR UMX1N TN G3070324 1- B g3
Q 2060 IC NJU7007F3-TE1 G1093617 1- B e1
Q 2061 TRANSISTOR DTC144EE TL G3070075 1- B e3
Q 2062 FET 2SK3541 T2L G3835417 1- B e3
Q 2064 IC LMV321IDCKR G1093969 1- A C3
Q 2065 IC TC4S66F(TE85R.F) G1090893 1- B f2
Q 2066 TRANSISTOR 2SA1602A-T111-1F G3116028F 1-5 A E2
Q 2066 TRANSISTOR 2SA1576A T106 R G3115768R 6- A E2
R 2002 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A F1
R 2003 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A F1
R 2004 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 2005 CHIP RES. 2.2 1/16W 5% RMC1/16 2R2JATP J24185229 1- A G3
R 2006 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G3
R 2007 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 2008 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F1
R 2009 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F1
R 2010 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A F1
R 2011 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B b2
R 2012 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A D1
R 2013 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F1
R 2014 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B b2
R 2015 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A F1
R 2016 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A F1
R 2017 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F1
R 2018 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A F1
R 2020 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F1
R 2021 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A F1
R 2022 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 2023 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D1
R 2024 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- A C1
R 2025 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A F3
R 2026 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A D1
R 2027 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E3
R 2028 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A C1
R 2029 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A D1
R 2030 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A E1
R 2031 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e3
R 2032 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A G3
R 2033 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A F3
R 2034 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A F3
R 2035 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A F3
R 2036 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A F3
R 2037 CHIP RES. 220 1/2W 5% RMC1/2 221JCTP J24275221 1- B b1
R 2038 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A F1
R 2040 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A F1
R 2041 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 2042 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b2
R 2043 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A E2
R 2044 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e1
R 2045 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B f1
R 2046 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f2
R 2047 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A E2
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
MAIN-2 Unit
Parts List
