41
R 2048 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B e1
R 2049 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f2
R 2050 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f1
R 2051 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B f3
R 2052 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f3
R 2053 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e3
R 2054 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B f3
R 2056 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B f3
R 2057 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B e1
R 2058 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A D1
R 2059 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g3
R 2060 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A D1
R 2061 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B g3
R 2062 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B g3
R 2063 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B g3
R 2064 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B g3
R 2065 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2066 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2067 CHIP RES. 100 1/4W 5% RMC1/4 101JATP J24245101 1- B c1
R 2068 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B d1
R 2069 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d1
R 2070 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B d1
R 2071 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 1- A E3
R 2072 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B d1
R 2073 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103 1- A F3
R 2074 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 2076 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A F2
R 2077 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- B f1
R 2078 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B f2
R 2079 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B g2
R 2080 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B e1
R 2081 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B g2
R 2082 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B e1
R 2083 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 2084 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B f1
R 2085 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B g2
R 2086 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B f3
R 2087 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A F2
R 2088 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B f4
R 2089 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- A F2
R 2090 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B g4
R 2091 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B g4
R 2092 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B f4
R 2093 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a2
R 2094 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2095 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f1
R 2096 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B c1
R 2097 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b3
R 2098 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e3
R 2099 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B d1
R 2100 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B d1
R 2101 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B d1
R 2102 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 2103 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G2
R 2104 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B e1
R 2106 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 2107 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B f1
R 2108 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g1
R 2109 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e1
R 2110 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B f1
R 2111 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 2112 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 2113 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B f1
R 2114 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B f1
R 2115 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B f1
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
–
Parts List
