Vertex Standard VX-424A Series User Manual

42
R 2116 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B f1
R 2117 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B f1
R 2118 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B f1
R 2119 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B f1
R 2120 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B g2
R 2121 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f1
R 2122 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g2
R 2123 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B g1
R 2124 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A F2
R 2125 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F2
R 2126 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A F2
R 2127 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A F2
R 2129 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b3
R 2130 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 2131 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 2132 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G2
R 2133 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 2134 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 2135 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B d2
R 2136 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 2137 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 2138 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c2
R 2139 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B g1
R 2140 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B g2
R 2141 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e3
R 2142 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B f2
R 2143 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B f2
R 2144 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B f2
R 2145 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B f2
R 2146 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 2147 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B b2
R 2148 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b3
R 2149 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B d2
R 2150 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d2
R 2151 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B d2
R 2152 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B d2
R 2153 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d2
R 2154 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B d2
R 2155 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B d2
R 2156 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 2157 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b3
R 2158 CHIP RES. 120 1/16W 5% RMC1/16S 121JTH J24189014 1- B b3
R 2159 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- B b2
R 2160 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b3
R 2161 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B c2
R 2162 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 2163 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b2
R 2164 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d2
R 2165 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2166 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 1- B e4
R 2167 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 1- B e4
R 2168 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A F3
R 2169 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g2
R 2170 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g2
R 2171 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A E2
R 2172 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B g1
R 2173 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A F3
R 2174 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A E3
R 2175 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A E4
R 2176 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b2
R 2177 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B c3
R 2178 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c3
R 2179 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c3
R 2180 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B c2
R 2181 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B c2
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
MAIN-2 Unit
Parts List
