Vertex Standard VX-424A Series User Manual

43
R 2182 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- B e2
R 2183 CHIP RES. 270 1/16W 5% RMC1/16S 271JTH J24189018 1- B e2
R 2184 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- B e2
R 2185 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- B e2
R 2186 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- B e2
R 2187 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B e2
R 2188 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B e2
R 2189 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B e2
R 2190 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A F1
R 2191 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2192 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A G1
R 2193 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- A G1
R 2194 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A E3
R 2195 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E3
R 2196 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2197 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A D3
R 2198 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2199 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f2
R 2200 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2201 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2202 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A E2
R 2203 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2204 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2205 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2206 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2207 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2208 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2209 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2210 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2211 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E3
R 2212 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A D4
R 2214 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2215 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2216 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2217 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2218 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2219 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2220 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2221 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2222 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2223 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2224 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E2
R 2225 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E3
R 2226 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 2227 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E1
R 2228 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 2229 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B g1
R 2230 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c3
R 2232 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e1
R 2234 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B f2
R 2235 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B e2
R 2236 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e2
R 2237 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- B f2
R 2238 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D3
R 2239 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D3
R 2240 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2241 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2242 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2243 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2244 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2245 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2246 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2247 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D3
R 2248 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E1
R 2249 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
MAIN-2 Unit
Parts List
