44
R 2250 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 2251 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 2252 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 2253 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 2254 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 2255 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 2256 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A D1
R 2257 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- A D2
R 2258 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A D1
R 2259 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B d3
R 2260 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e3
R 2261 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- B e3
R 2262 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B e3
R 2263 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B d3
R 2264 CHIP RES. 820k 1/16W 5% RMC1/16S 824JTH J24189060 1- B d3
R 2265 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d3
R 2266 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e3
R 2267 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d4
R 2268 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B f3
R 2269 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B d4
R 2270 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e2
R 2271 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B d3
R 2272 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B d4
R 2274 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e2
R 2275 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e2
R 2276 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A D3
R 2277 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D3
R 2278 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D3
R 2279 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A C3
R 2280 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D3
R 2281 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C3
R 2282 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D2
R 2284 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B g3
R 2286 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d4
R 2287 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D4
R 2288 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 2289 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 2290 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B f3
R 2291 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B f3
R 2292 CHIP RES. 18 1/16W 5% RMC1/16S 180JTH J24189004 1- B d2
R 2293 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B e1
R 2294 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a3
R 2295 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d2
R 2296 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- B d2
R 2297 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 16KEY 1- B e4
R 2298 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 16KEY 1- B e4
R 2301 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B g2
R 2302 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B f2
R 2303 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B g1
R 2304 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- A G3
R 2306 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f2
R 2307 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A E2
R 2309 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 2310 CHIP RES. 18k 1/16W 5% RMC1/16S 183JTH J24189040 1- B e3
R 2311 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 2313 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B d3
R 2316 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B g3
R 2317 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C3
R 2320 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e3
R 2321 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 2322 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 2323 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B e1
R 2324 CHIP RES. 68k 1/16W 0.5% MCR01MZPD6802 J24189384 1- B g1
R 2325 CHIP RES. 7.5k 1/16W 0.5% MCR01MZPD7501 J24189393 1- B g1
R 2326 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d3
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE
LAY ADR
MAIN-2 Unit
Parts List
