LD-16 Door Operator - Modernization Integral Cab Header Installation
October 2021 - 88420 v.1.0
25
Single-Speed Center-Opening Doors Integral Cab Header Installation
(continued)
Figure 21 - Door Operator Machine Installation (2 of 2)
Angles are Almost Flush with Top of Door Operator
Add Mounting Bolts to Brace the
Cab to the Door Operator Back
Attach These Angles
(if not already on header)
9¼"
Position the Angle with the Bolt
Loose Enough to Adjust the Height
when Setting the Operator in Place.
To Next Page
