Replacement Parts LD-16 Door Operator - Modernization
84 © Vertical Express
Replacement Parts
ITEM PART NO. DESCRIPTION
1 9732100 Hanger Roller, D94 x 19 mm with Bushing
2 9732202 Counter Roller, D30 x 9 mm with Shaft
3 9732305 Buffer Cup
4 9731714 Buffer
5 9731313 Door Contact
6 9731416 Door Contact Bridge
7 9731910 Synchronization Rope, L= 5010
8 9732019 Synchronization Rope, L=1750 mm
9 9732317 Coupler Contact Bridge
10 9732718 Rope Diverting Pulley, Left
11 9733012 Rope Diverting Pulley, Right
12 9747977 Rubber Puffer
13 9732240 Fixing Screw (for clutch), M8 x 20 mm
14 9733310 Belt, L=3000 mm, SS <=42"; SS-C/O,<=48"
15 9731325 Belt, L=3900 mm, All Others >46"
16 9731428 Belt Diverting Pulley
17 9731726 Belt Diverting Pulley, Left
18 9731829 Door Drive Control Box - Standard
19 9731921 Door Drive Control Box with CAN Interface
20 9732123 Motor Unit Midi, C/O, LH
21 9732226 Motor Unit Midi, C/O, RH
22 9732329 Motor Unit Supra, C/O, LH
23 9733127 Motor Unit Supra, C/O, RH
24 9733220 Motor Unit, Double Coupler Main, LH
25 9731349 Transformer (Universal Trafo)
26 9731337 Magnet Switch, L=220 mm
27 9731430 Magnet
28 9731933 Belt Fixing Clamp
29 9732238 Belt Fixing Clamp, Main Belt
30 9732330 Belt Fixing Clamp, Second Belt
31 9733139 Service Switch, Electrical Box
33 9731829 Wittur Door Drive Control Box Kit, Discrete
34 9371921 Wittur Door Drive Control Box with Can Interface Kit, Serial
32 9736918 Wittur Programming Tool (WPT), see next page.
