Vertical Express LD-16 - Car or Hoistway Door Weight

Calculate Minimum Door Closing Times LD-16 Door Operator - Modernization
78 © Vertical Express
Car or Hoistway Door Weight
SINGLE SPEED SIDE OPENING Weight Density = 7.600
Door weights include allowance for door hangers, clutch, crank, etc.
The IMS Monitor variable, MASS, can be used to determine total door weight for label.
120 208 221 234 247 260 273 285 298 311
118 205 218 230 243 255 268 281 293 306
116 202 214 226 239 251 264 276 288 301
114 198 210 222 235 247 259 271 283 296
112 195 207 219 231 243 255 267 279 291
110 191 203 215 227 238 250 262 274 285
108 188 199 211 222 234 246 257 269 280
106 184 196 207 218 230 241 252 264 275
104 181 192 203 214 226 237 248 259 270
102 178 188 199 210 221 232 243 254 265
100 174 185 196 206 217 228 238 249 260
98 171 181 192 202 213 223 234 244 255
96 167 178 188 198 208 219 229 239 250
94 164 174 184 194 204 214 224 234 244
92 160 170 180 190 200 210 220 229 239
90 157 167 176 186 196 205 215 225 234
88 154 163 172 182 191 201 210 220 229
86 150 159 169 178 187 196 206 215 224
84 147 156 165 174 183 192 201 210 219
82 143 152 161 170 178 187 196 205 214
80 140 148 157 166 174 183 191 200 209
32 34 36 38 40 42 44 46 48
DOOR OPENING WIDTH
DOOR OPENING HEIGHT
