Figure 3.63 Breaker for Vertiv 40k Input Disconnect N
Figure 3.64 Breaker for Vertiv 80k Input Disconnect N
Transfer from Maintenance Bypass Mode to Line Mode:
1. Put in ON position the Line input breaker, the Bypass input breaker and the Output switch. The fans and the LCD
will switch ON and the LCD will shown that the UPS is in Bypass Mode.
72 Proprietary and Confidential ©2024 Vertiv Group Corp. 3 Operations
Vertiv™ Liebert® MTP Online UPS User Manual 20-40-80kVA
