7.3.3 Accessing the Bottom Fan Filter
NOTE: Only transformer-based frames have bottom fans.
1. Remove the three lower bezels at the bottom of the frame.
2. Remove the screws and take out the filter, shown in Figure 7.3 below, and clean the filters as
described in Cleaning Fan Filters on page 77.
3. Replace the filter and bezels.
Figure 7.3 Replacing/Cleaning the bottom fan filter
ITEM DESCRIPTION
1 Filters
Vertiv | Liebert® APS™ Installer/User Guide | 79
