Vertiv Liebert DSE - Page 105

REV : 5
REV DATE : 5/18
DPN003175
Page :1 /1
DOWNFLOW AIR COOLED DA125, DA150 & DA165 MODELS
Form No.: DPN001040_REV4
CABINET DIMENSIONAL DATA
LIEBERT DSE
Model No. Approximate Dry Weight lb(kg)
DA125 3465 (1572)
DA150/DA165 3574 (1621)
48"
1219mm
24"
610mm
Filter Plenum
Shipped separately
Striated area indicates the recommended
minmum clearance to be provided for
component access.
Shaded area indicates the required minimum clearance
below the unit to lower the fans into the floor.Fans may
also remain in their shipped position if desired.
Filters are removed thru
front of plenum
Front View
Top View
117 11/16"
2989mm
Opening
42"
1067mm
Opening
5/16"
8mm
Bezel
47"
1194mm
45"
1143mm
1 3/16"
29mm
Handle
144"
3658mm
18"
457mm
76"
1930mm
Base Unit
142"
3607mm
94"
2388mm
Total Height
1"
25mm
Typ.
45"
1143mm
Plenum
47"
1194mm
45"
1143mm
1"
25mm
Typ.
Secondary Refrigerant
Piping Entrance
19"
483mm
2 5/8"
67mm
3 3/8"
86mm
7"
178mm
1
Notes:
1. 7" for DA125, 4" for DA150 & DA165.
