DOWNFLOW DA050-DA085 MODELS
Form No.: DPN001040_REV4
PLENUM DIMENSIONAL DATA
LIEBERT DSE
A
12"
305mm
H
34"
864mm
Hinged door for
filter access
Return air inlet opening
Height in (mm)
H
20 (508)
24 (610)
30 (762)
36 (914)
1"
25mm
32 1/8"
816mm
Opening
7/8"
22mm
Typ.
B Opening
76"
1930mm
A B C D E
DA080-DA085 Digital Scroll Models 82-1/4 (2089) 80-1/2 (2045) 100-1/16 (2542)
DA050 Digital Scroll Models 59-1/4 (1505) 57-1/2 (1461) 77-1/16 (1957)
16-15/16 (430) 17-13/16 (452)
Plenum Dimensional Data in (mm)
D
C Opening
E
Notes:
1. Only available on DA080-DA085 model.
1
Plenum
