Vertiv Liebert DSE - Page 123

REV : 2
REV DATE : 6/18
DPN004081
Page :1 /1
UPFLOW 80kW-85kW W/ EC FANS
Form No.: DPN001040_REV4
PLENUM DIMENSIONAL DATA
LIEBERT DSE
2
Notes:
1. All Plenums to be field assembled and EC Fans wired to unit.
2. Shaded areas indicate a recommended minimum clearance of
36" (914mm) from the bottom of the unit to the top of the plenum.
3. Must have access to remove Front Grill or panel to remove EC Fans.
4. Top duct flanges on plenum top for Supply Air ducting when
solid panel plenum is used.
5. See DPN004084 for additional information.
B
A
7/8"
22mm
4
A B C D
82-1/4 (2089) 34 (864) 81 (2057) 32 (813)
Plenum Dimensional Data in. (mm)
7/8"
22mm
F
5
E
Non-grilled plenum Front discharge Rear discharge
24 (610) 112 (51) 160 (73) 173 (79)
30 (762) 136 (62)
36 (914) 156 (71)
N/A
Main unit
Plenum
Height E
in. (mm)
Main unit Plenum weight lb. (kg)
24 (610) 27 (12)
30 (762) 30 (14)
36 (914) 33 (15)
17 (432)
Compressor Plenum
Width
G
in. (mm)
Height
F
in. (mm)
Weight
lb ( kg)
2 102 (46)
No. of
Fans/Unit
EC Fan Assembly Weight lb. (kg)
G
I.D.
C
Duct Flange
D
Duct Flange
