USER MANUAL-S600E
21
S600E
Remove the fixing structural parts Inserting direction
Standard UPS
Figure 2-2 Removing the bottom pallet
3.
After moving the cabinet to the installation site, you raise the adjustable feet and use the castors to move the
cabinet to its final installation position, finally, rotate the adjustable feet until they are in contact with the floor. See
Figure 2-3 for the finished installation.
1. It is not necessary to install the fastening structural parts of the bottom pallet in the case of UPS with side cabinet
