USER MANUAL-S600E
48
S600E
Input neutral lost
The AC input mains N line
has not been detected. Please check whether the input N line has been interrupted
or disconnected
Check whether the PE line is connected securely, and that the alarm can
Input phase reversed
B by 120 degrees.
Check that the UPS mains input phase sequence is correct. If not, correct it
Input abnormal
The rectifier and charger have switched off
because the mains voltage and frequency values exceed the
normal operating range. Check whether the rectifier input phase voltage and frequency exceed the normal range
or the mains power has been switched off
Rectifier overload
exceeds the rectifier overload point. Check that the input voltage meets the output load
requirement, a mains input range 176V - 100V corresponds to a load range of 100% - 50%, with linear derating
Battery reversed
battery cable connections
Battery low pre
warning
This alarm is generated when the battery reaches the EOD (End Of Discharge voltage). The battery
continue to provide full load discharge capacity for another two minutes after this warning appears. The user
can set this value ranging from 2min
～
30min, (2 min by default). Please shut down the load as quickly as
possible
abnormal
y is connected, the system checks whether the battery voltage exceeds the normal setting
range. Check whether the battery terminal voltage exceeds the normal setting range
Check the battery and battery cable connections
qualified
The actual number of connected battery cells differs from the setting. Modify either the number of batteries
or the setting so that these two values are consistent
The battery capacity is less than 25% of the initial value.
Battery replacement is recommended
Battery test fail
The battery low voltage is detected during the manual or periodic battery self
recommended
Battery overtemp
The battery ambient temperature is too high. Check
whether the battery ambient temperature exceeds the
setting value of 40 -
60
ª
(default:
50
ª
)
connected
The battery cabinet is not connected to the system
At least one fan is faulty. Check whether the fan is blocked or the
cables have been disconnected
System overtemp
cancelled
by reducing the heat sink temperature of each module to within the setting range. The system will
restart automatically once the fault has been resolved.
In the event of overheating, please check:
1.
If the ambient temperature is too high
2.
If the ventilation holes are blocked by dust
3.
That the fans are working correctly
Inverter overload
The inverter load demand is exceeds the rated value, the overload delay time has expired, and the inverter has
shut down. If the bypass is available, the UPS will transfer to bypass mode, otherwise the output to the load will
be interrupted Check that the current inverter load demand, if it is overloaded, simply reduce the load demand
and the system will revert to inverter mode five minutes after the alarm condition has been cleared
Bypass phase
reversed
The bypass voltage phase sequence is reversed. Normally, phase B lags phase A by 120 degrees, and phase C
lags phase B by 120 degrees.
Check that the UPS bypass input phase sequence is correct. If not, correct it
Bypass overcurrent
The bypass current exceeds the rated value. The overload delay time has expired and the inverter has shut
down
connection abnormal
check that the bypass cable connection is the same as the configured phase number
Bypass abnormal
This may be caused by the bypass voltage and frequency being outside the acceptable range, the bypass
being switched off or by the bypass cables being connected incorrectly
1.
Check that the bypass voltage and frequency are within the setting range.
2.
Check the bypass cable connections
ECO mode
bypass input voltage and frequency are within the setting range.
Output LPE short
There is a short circuit between the output and the enclosure Check for short circuits between the output
cables and the enclosure
