Vertiv RPC2 - SNMPv3 Access Configuration; SNMPv1;v2 Traps Configuration

SNMPv3 Access
From the side navigation bar of the System tab, click SNMP-V3 Access to configure the SNMPv3 community's settings. Up
to 20 devices can be configured with permission to access the RPC2 communications module, identified by IP address or
hostname, read/write privileges and a community string.
PARAMETER DESCRIPTION
Entry As many as 20 devices can be configured for access.
User Enable
User Enable must be checked for each user to be configured for access. A maximum of 20 devices may be configured for
access.
User Name The IP address of the network host to receive access to device information or traps.
Authentication Type Options are none, MD-5 or SHA.
Authentication
Secret
Password between 8-64 characters for SNMPv3 request.
Privacy Type Options are no encryption or DES.
Privacy Secret Password of 8-64 characters for SNMPv3 request.
Access No Access provides no access. ReadOnly provides only the ability to view data.
Source Either an IP address or the network name of the host. To enable multiple hosts, enter network names separated by a comma.
Clear Click Clear to delete all values for this entry.
Table 3.8 SNMPv3 Access Description
NOTE: A configuration with sources set to 0.0.0.0 with write access and no authentication grants access to any host
computer.
SNMPv1/v2 Traps
An administrator can configure up to 20 users to receive notifications from the RPC2 communications module, identified by
IP address or hostname, trap listen port and community string.
To configure SNMPv1/v2 traps:
1. From the side navigation bar of the System tab, click Manage Protocol - SNMP - V1V2 Traps.
2. Enter the network name, port number and community string in the appropriate fields.
3. Check the box to enable the heartbeat feature.
4. Click the Save icon in the upper-left of the window.
5. To verify the configuration, click the Verify icon at the upper-left of the window.
PARAMETER DESCRIPTION
Entry Enter up to 20 targets to receive traps.
Network Name The IP address or network name of the target to receive traps.
Port The Trap Listen Port where traps will be sent. Use 162 if the host computer uses standard ports.
Community The community string used the by the IP host for this entry (case sensitive, up to 32 characters).
Heartbeat Check the box to enable a heartbeat check.
Clear Click Clear to delete all values for this entry.
Table 3.9 SNMPv1/v2 Trap Descriptions
Vertiv | RPC2™ Communications Module Installer/User Guide | 28
