4. Place the washer and the sealing nut on both sides of the front wheel axle (Fig. 4)
Take care not to scratch the fork paint while performing this operation.
Required tools to perform these operations: 1 5mm Allen key and 2 15mm wrench keys
Retrace all the instructions step by step to verify you
haven’t
missed any key passage. Finally check you have
firmly tightened the front wheel.
5. Use the provided 2x 15mm wrench key to tighten the front wheel nuts (Fig. 5)
6. Go back to step 2 and perform the reverse procedure in order to reinstall the brake caliper.
3. Slide the wheel inside the fork. The front wheel has 2 washers, 2 spacers and 2 nuts. Keep the nut and slide it in the
axle, placing 1 spacer on each side (Fig. 3)
