Vespa LX 2012 User Manual

- Disconnect the fuel hoses and the main cable
harness from the injector.
- Disconnect the main cable harness from the en-
gine temperature sensor.
- Disconnect the two magneto flywheel cable har-
ness connectors, slide them out from the bottom
and free the cable tie that joins them to the main
cable harness.
- Disconnect the flywheel cables retainer bracket
from the engine.
Engine from vehicle Vespa LX - S 125 3V ie 150 3V ie (2012)
ENG VE - 112

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
