Cooling hood
- Unscrew the five indicated screws and remove
the cooling cap.
Cooling fan
- Remove the front part of the fan, unscrewing the
three fixing screws.
- Using the specific tool, unscrew the cooling fan
fixing screw.
- Remove the fan.
- Recover the wrench.
Specific tooling
020442Y Pulley lock wrench
Vespa LX - S 125 3V ie 150 3V ie (2012) Engine
ENG - 135
