- Undo the screw «B» and remove the front han-
dlebar cover.
- Disconnect the electric terminal of the low/high
beam headlight bulb and remove the turn indicator
bulb.
THE FOLLOWING INDICACTIONS REFER TO THE LX VERSION.
Proceed as follows:
-Remove the rear-view mirrors.
- Undo the two screws indicated.
- Undo the screw under the headlamp.
- Laterally release the handlebar cover end.
- Disconnect the electrical terminals and remove the front handlebar cover.
Vespa LX - S 125 3V ie 150 3V ie (2012) Chassis
CHAS - 239

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
