Taillight assy.
- Undo the two fixing screws and remove the rear
light unit.
- Undo the screw indicated and disconnect the
connector.
Footrest
- Remove the leg shield back plate.
- Remove the side fairings.
- Remove the central tunnel inspection door.
From both sides, unscrew:
- The fixing screw at the back.
- The fixing screw on the central part.
Chassis Vespa LX - S 125 3V ie 150 3V ie (2012)
CHAS - 242
