Maintenance
66
V-belts
Safety concerning maintenance work on the transmission
When working on the transmission the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected in
accordance with the instructions serious accidents causing damage to
limbs can occur.
When working on the transmission:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The PTO shaft must be disconnected.
• The tractor hydraulic system must be disconnected.
• The hand brake must be activated.
After 10 working hours
Thereafter, every 40
hours of use
»Maintenance intervals« page 52
The V belt transmission is checked in the following way:
Remove the bolts and remove the guard.
Check that the V-belts can be depressed by approx. 15 mm
(
19
/
32
'')
between the V-belt pulleys as shown.
