Maintenance
70
Changing the oil
After 10 working hours
Thereafter, every 200 hours
of use
Or once a year
»Maintenance intervals« page 52
The oil in the cutterbar is changed as follows:
Activate the tractor's lift arms and raise the machine completely
free of the ground.
Pull in the cord and release the lock catch.
Hold in the string and activate the tractor's hydraulics and the
machine will be raised up to the transport position.
Release the cord once the cutting unit is raised approximately
halfway up.
Release the pressure in the hydraulic system.
Locate the drain plug and remove it.
Let the oil flow into a suitable container.
Allow the last of the oil to drip out of the cutterbar for approx. 10 -
15 minutes.
Fit the drain plug into the cutterbar and tighten it fully.
Min. 100 mm (3
15
/
16
'')
Cord
