Maintenance
71
Activate the tractor's hydraulic system and lower the machine
down to the working position.
Place the machine on a level surface.
Check the position of the cutterbar.
Remove the oilplug.
Fill up with the new oil until the oil level is as shown.
Min. 6 mm (
1
/4”) - max 9 mm (
3
/8”)
»Lubricants« page 94
Fit the oilplug and tighten it fully.
Model Litre
(approx.)
Pints (US)
(approx.)
Pints (Imp.)
(approx.)
117 2.4 5.1 4.2
122 2.9 6.1 5.1
124 3.1 6.5 5.4
