Maintenance
81
V-belts
Safety concerning maintenance work on the transmission
When working on the transmission the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected in
accordance with the instructions serious accidents causing damage to
limbs can occur.
When working on the transmission:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The PTO shaft must be disconnected.
• The tractor hydraulic system must be disconnected.
• The hand brake must be activated.
As required
Once the V-belt transmission starts having problems transmitting
power to the cutterbar, it must be changed.
»Maintenance intervals« page 52
The V-belts are changed in the following way:
Use a suitable tool to remove the guard.
Remove the spring catch.
