The VA388 is equipped with steam nozzles of the
cool touch series. These steam nozzles, thanks
to the presence of an internal Teflon tube, do not
heat up quickly. In this way, the bartender has
a chance to work more comfortably even on an
ongoing basis, without the fear that the steam
nozzle may reach excessive temperatures.
REASSEMBLY
During the reassembly phase it is important to
lubricate the seals of the piston in contact with
the lever, to ensure fluid movement inside the
housing.
To access the Teflon tube for replacement it is
sufficient to hold the steam nozzle and unscrew
the top anticlockwise with a No. 9 wrench.
To remove the dispensing nozzle it is sufficient to
unscrew the lower part of the nozzle by hand. We
suggest an annual replacement of the O-ring that
holds the gasket.
Edition 01 of 08/2017
7.23
SERVICE MANUAL
Fig. 254
Fig. 257
Fig. 256
Fig. 255
