5.9.2.2 Matrix settings
Inside the matrix, both jumpers JP1 and JP2 should be set up for RS232 type communication, as shown in the
drawing.
Dip switch SW1 is used to select the baud rate:
Baudrate dip 3 dip 4
9600 baud ON ON
1200 baud OFF ON
Refer to the respective ma
nual for further information.
5.9.2.3 Keyboard settings
While the keyboard is being set up, the submenu should be set as
follows:
Control of a SW164OSM matrix.
Even in the presence of more than one keyboard connected to the matrix, the identification number of each
keyboard is of no importance.
5.9.2.4 Operational test
If the keyboard is connected directly with the switcher set up in this way using the telephone cable supplied, it
should be possible to switch the input videos immediately:
press to select monitor 1
press , , to select the cameras.
