5.13.4 Configuration
The multiplexer is configured by On Screen Menu and a configuration dip switch on the back of the unit. Refer
to the corresponding manual for an explanation of the various configuration items.
The multiplexer should be configured for RS485 type communication, with an appropriate identification address
and baud rate.
5.13.4.1 OSM Configuration
Connect the multiplexer directly to the keyboard and a monitor to the MONITOR 1 output.
starts multiplexer configuration.
The multiplexer shows the on screen menu; the keyboard display indicates the mode change:
/ : increase and decrease the selected value
enters the next menu
equivalent to the NEXT key
end of configuration
Joystick
: movement within the menus.
5.13.5 Dedicated Functions
As well as the normal procedure for selecting input videos, the Sony multiplexer is provided with numerous
other functions that are activated by pressing key combinations corresponding to the keys on the multiplexer’s
local keypad.
The
key is used to change the number of the unit responding to the command.
5.13.5.1 Multiplexer functions
multi
quad
option
freeze
live
vcr
