5.15.6 Choice of protocol
The Sanyo protocol provides two different controls for choosing the main/spot monitor and for switching. When
Mux Sanyo is selected the most recent protocol is offered but this may not be compatible with obsolete
multiplexer models.
It is possible to select one of the two protocols if the current setting does not allow switching. The type of
protocol is stored and kept if the keyboard is switched off and on again.
: Selects the most recent protocol (default)
: Selects the traditional protocol.
5.15.7 Indications on the display
The display shows the controlled monitor indication after the unit number:
indicates the main monitor
, , , indicate the spot monitors.
