6.16.3.1 OSM Setup
Connect the dome directly to the keyboard and connect a monitor to the dome video outlet.
The DCJ keyboard enters special mode while the dome is being set up.
starts dome setup.
The dome shows the menu on video; the keyboard shows the mode change on the display:
setup end
Joy
stick
: movement within the menus
Zoom
, Focus / , Iris / when present
: enter submenus
: ‘5’ key when necessary, as specified in the dome manual
6.16.4 Autopan
: start autopan
: stop autopan
6.16.5 Preset, scan, home, patrol
Warning! The ‘Scan’ and ‘Patrol’ instructions given in the dome manual do not correspond to commonly
accepted use in this manual: for practical purposes the functions take on the ‘standard’ meaning and not that
suggested by the dome manual:
‘preset’ (associated with the key) means storage of the present position
‘scan’ (associated with the key) means the pan & tilt movement towards a previously stored position;
in the dome manual this function is called ‘preset’
‘patrol’ (associated with the key) means a series of scans, where the previously stored positions are
shown one after the other in sequence; in the dome manual this function is called ‘scan’.
The storage of the preset position is different for each dome model:
SCC-641P: only from On Screen Menu
SCC-643P: from On Screen Menu or from keyboard through direct control keys.
(0÷127): movement towards previously stored preset position X
(0÷127): storage of the preset position X (only for the model SCC-643P)
: movement towards the Home position, corresponding to preset position 1
: start patrol
: stop patrol
