Page 117
MNVADCJ01_1729_EN
6.20.6 Camera setup
The dome allows the enabling of IR mode and automatic autoflip; These parameters are setup at the same time.
Only some VCL models allow the one-colour changeover. In case of infrared illumination, the IR mode is
suggested. The autoflip, when enabled, consists of a 180° dome rotation when the limit switch is joined towards
the low.
For all setup operations the keyboard must be enabled to perform the receiver setup (menu
).
: IR mode disabled, autoflip disabled
: IR mode enabled, autoflip disabled
: IR mode disabled, autoflip enabled
: IR mode enabled, autoflip enabled.
6.20.7 Lenses
Autofocus: on, off
Autoiris:
on, off
Cha
nge mono/colour:
on/off (toggle), automatic
6.20.8 Other functions
autoflip
Alarm mode:
on, off
Relay
:
on, off
washer on
wiper on
