6.22 Videotec receivers with Videotec protocol
6.22.1 Reference material
Videotec telemetry receivers:
DTRX1, DTRX3 (with Videotec protocol), DTRXDC, DTMRX1, DTMRX2, MICRODEC
6.22.1.1 Receiver settings
The new generation of Videotec receivers allows the choice of two protocol types (Videotec and Macro).
The chapter refers only to the Videotec protocol.
For all setup operations the keyboard must be enabled to perform the receiver setup (menu
).
Receiver ID-number must be set according to the respective installation manual.
Baudrate can be selected among the following values: 1200, 9600 (default).
6.22.1.2 Keyboard settings
During Keyboard setup, submenu  must be suitably set:




Videotec Receivers
Baudrate must be equal to the one selected for the receiver.

6.22.2 Connexion
6.22.2.1 Cable
The Videotec and Linxs receivers can be connected directly to the keyboard using the telephone cable supplied
(for testing and checks) or a telephone cable for distances of up to 1200 using the standard connection cable
described in § 3.3 - Standard connection cable, page 12.
6.22.3 Preset, scan, home
 (1÷14): store the present position as preset position number X
(1÷14): movement towards previously stored position X
: movement towards the Home position corresponding to preset position 1
6.22.4 Autopan
 autopan on/off (toggle)
