13
Buttons and icons in function area B
Display Vitotronic 300 Vitotronic 100
Gas condensing boiler in multi boiler system
Colour of the flame :
Blue Burner in operation
Grey Burner off
Red Boiler in a fault state
Colour of the flame :
Blue Burner in operation
Grey Burner off
Red Boiler in a fault state
Oil condensing boiler in multi boiler system
Colour of droplet :
Yellow Burner in operation
Grey Burner off
Red Boiler in a fault state
Colour of droplet :
Yellow Burner in operation
Grey Burner off
Red Boiler in a fault state
1, 2, ... Boiler number
The boiler with the Vitotronic 300 is always boiler
number "1".
Boilers with the Vitotronic 100 are numbered "2"
to "8".
Boiler disabled Boiler disabled
Denotes the lead boiler Denotes the lead boiler
75 °C Common flow temperature Current boiler water temperature
85 °C — Specified set boiler water temperature
600 kW Current heating output of the boiler Current heating output of the boiler
Note
The current burner output is shown by bars at the bot-
tom of the boiler that are the same colour as the fuel:
■
1 bar corresponds to ⅓ of the maximum boiler output
■
2 bars correspond to ⅔ of the maximum boiler output
■
3 bars correspond to the maximum boiler output
Buttons in navigation area C
Display Vitotronic 300 Vitotronic 100
Call up the home screen Call up the home screen
■
One step back in the menu
or
■
Cancellation of started setting
■
One step back in the menu
or
■
Cancellation of started setting
Confirm an entry or selection Confirm an entry or selection
Call up a help text Call up a help text
/
■
Scroll through the menu
or
■
Switch to other display areas, e.g. to the "En-
ergy cockpit"
■
Scroll through the menu
or
■
Switch to other display areas, e.g. to the "Ener-
gy cockpit"
Note
These icons are not always displayed, but appear sub-
ject to the system version and the operating condition.
Explanation of all buttons and icons: See page 51.
Note
You can lock the controls for the home screen: See
chapter "Locking the controls".
If you do so, you will not be able to make adjustments
on either the home screen or the main menu. "Panel
locked" is displayed.
Control unit operation
Home screen: Displays and settings (cont.)
5863758
