Vitotronic 100 — scans for every boiler
Subject to the connected components
and settings made, you can scan current
temperatures and operating conditions.
Press the following keys:
1. for settings; " " flashes.
2. until " " flashes.
3. OK to confirm.
4. / for the required information.
5. OK to confirm; if you want to reset
the value to "0" (see following
table), " " flashes.
6. OK to confirm; the value is reset.
Example:
On the display, you can see the number
"3" and the current boiler water temper-
ature.
¸
3 6 5
°C
Note
The scan mode terminates automatically
after 30 min or if you press .
The information appears in the following sequence:
Display Explanation Notes
0 1 LON subscriber number Control unit has subscriber num-
ber 1.
2 107 °C Flue gas temperature Displayed only if a flue gas tem-
perature sensor is connected.
3 65 °C Boiler water temperature —
6 55 °C Temperature sen-
sor
aJA
Only if a sensor is connected.
7 55 °C Temperature sen-
sor
aJB
Only if a sensor is connected.
2 6 3 5 7 2 h Hours run, burner single
stage, stage 1 or modu-
lating
With "D" you can reset the value to
"0".
1
2 6 3 5 7 2 h Hours run, burner
stage 2
With "D" you can reset the value to
"0".
2
0 1 3.5 7 8 Burner starts With "D" you can reset the number
of burner starts to "0".
3
0 0 1 2 2 5 Fuel consumption With "D" you can reset the value to
"0".
4
Scanning options
Scanning information
