1.1 Product description
Low temperature oil/gas boiler
For operation with modulating boiler water temperature
Permissible flow temperature (= safety temperature) up to 110 ºC (up
to 120 °C on request)
Permissible operating pressure 4 bar
■ CE designation: CE-0085BQ0020
– according to Efficiency Directive 92/42/EEC (up to 350 kW)
– according to Gas Appliances Directive 2009/142/EC
■ Economical and environmentally friendly through modulating boiler
water temperature.
Standard seasonal efficiency [to DIN] for operation with fuel oil:
89 % (H
s
)/95 % (H
i
).
■ Optional stainless steel flue gas/water heat exchanger for higher
standard seasonal efficiency [to DIN] through condensing technol-
ogy.
■ Three-pass boiler with low combustion chamber loading for clean
combustion with low emissions.
■ Wide water galleries and large water content provide excellent nat-
ural circulation and safe heat transfer.
■ Integral Therm-Control start-up system for easy hydraulic connec-
tions – a shunt pump and a return temperature raising facility are not
required.
■ Low water indicators are not required up to 300 kW.
■ Compact design for easy transportation and economical use of
space – important for modernisation projects.
■ Vitoflame 100 to 270 kW Unit pressure-jet oil/gas burners are avail-
able.
■ Fastfix assembly system for control unit and thermal insulation.
1.2 Operating conditions with Vitotronic boiler control units and Therm-Control
Requirements
Operation with burner load
≥ 60 %
< 60 %
1. Heating water flow rate None
2. Boiler return temperature (minimum value)
*1
None
*2
3. Low-end boiler water temperature – Oil operation 50 °C – Oil operation 60 °C
– Gas operation 60 °C – Gas operation 65 °C
4. Two-stage burner operation Stage 1; 60 % of rated output No minimum load required
5. Modulating burner operation Between 60 and 100 % of rated output No minimum load required
6. Reduced mode Single boiler systems and lead boiler of multi-boiler systems
– Operation with the low-end boiler water temperature
Lag boilers of multi-boiler systems
– Can be shut down
7. Weekend setback As per reduced mode
Note
For water quality requirements, see page 44.
*1
For a corresponding sample application using the Therm-Control start-up system, see technical guide sample applications.
*2
No requirements only in conjunction with Therm-Control.
