9.1 Specification
Accessories for heating circuits
Divicon heating circuit distributor
for boilers up to 335 kW
Specification
Construction and function
■ 1 to 4 heating circuits can be connected to the flow distributor and
return collector.
■ Free connections are closed via dummy flanges (part of the standard
delivery).
■ The flow distributor and return collector can optionally be arranged
on the r.h or the l.h side of the boiler.
■ Thermal insulation for the Divicon heating circuit distributor is part of
the standard delivery.
Divicon heating circuit distributor, installed adjacent to the boiler
For Vitorond 200, 125 to 270 kW, Vitoplex 200, 90 to 270 kW, Vitoplex
300, 90 to 300 kW, Vitoradial 300-T, 101 to 335 kW and
Vitocrossal 200/300, 87 to 314 kW.
The Divicon heating circuit distributor can also be placed near the
boiler (as an alternative to wall mounting) by means of its separate feet
and on-site pipe connections.
Installation accessories
OIL/GAS BOILERS
VIESMANN
19
5822 426 GB
