Delivered condition
Boiler water temperature sensor
1 bag with technical documentation
Only for multi-boiler systems:
LON communication module and connecting cable for the data
exchange between control units
Heating system with DHW cylinder
Order separately; single boiler systems only:
Cylinder temperature sensor and circulation pump with check valve
for regulating the cylinder temperature
or
Vitotrans 222 primary store system with mixer assembly and cylinder
temperature sensor
Communication
The LON communication module (accessory) is required for commu-
nication with other control units, e.g. with the Vitotronic 200-H.
11.4 Vitotronic 200, type GW1, part no. 7248 084
Specification
Construction
The control unit comprises a standard unit, electronic modules and a
programming unit.
Standard unit:
ON/OFF switch
TEST key
Emissions test switch
Optolink laptop interface
Temperature controller
DIN TR 77708
or
DIN TR 96808
High limit safety cut-out
DIN STB 116907
or
DIN STB 98108
Operation and fault displays
Plug connection chamber
Connection of external equipment via a system plug
Connection of three-phase consumers via additional contactors
Programming unit:
With digital time switch
Backlit display with plain text support
Adjustment and display of temperatures and codes
Fault message display
All adjustments and the most important codes as plain text
Rotary selector for the temperature in standard mode
Keys:
Temperature for reduced mode
Program selection
Holiday program
Party and economy mode
DHW temperature
Heating curve for boiler water temperature (= system flow tem-
perature)
Time/Date
Functions
Weather-compensated control of the boiler water temperature
(= system flow temperature)
Electronic maximum and minimum temperature limit
Demand-dependent heating circuit pump and burner stop (not for
burners on boilers with a low-end boiler water temperature limit)
Adjustment of a variable heating limit
Anti-seizing pump protection
Integral diagnostic system
Flue gas temperature monitoring with flue gas temperature sensor
Maintenance display
Adaptive cylinder thermostat with priority control (heating circuit
pump OFF)
Auxiliary function for DHW heating (short-term heating to a higher
temperature)
Control of a primary store system with mixer assembly (only availa-
ble as an alternative to the control of a constant return temperature
raising facility with a regulated three-way valve)
Optional connection of external fault messaging
With boiler protection function subject to boiler version:
Therm-Control start-up system
Shunt pump control
Control of a constant return temperature raising facility with a
regulated three-way valve (only available as an alternative to the
control of a primary store system with mixer assembly)
The requirements of DIN EN 12831 for heat load calculation are met.
To reduce the heat-up load, the reduced room temperature will be
raised in case of low outside temperatures. The flow temperature will
be raised for a limited time to reduce the heat-up time after a setback
period.
According to the Energy Savings Order [Germany], the temperature in
each room must be individually controlled, e.g. through thermostatic
radiator valves.
Control characteristics
P-characteristics with two-point output when using a burner with
multiple stages
Pl characteristics with three-point output when using a modulating
burner, if installed
Thermostat for limiting the max. boiler water temperature:
95°C, adjustable to 100°C
Adjusting the high limit safety cut-out:
110°C, adjustable to 100°C
Heating curve setting range:
Slope: 0.2 to 3.5
Level: 13 to 40 K
Max. limit: 20 to 130°C
Min. limit: 1 to 127 °C
Range of the set DHW temperature:
10 to 60°C; can be changed to 10 to 95°C
Boiler coding card
For matching to the boiler (supplied with the boiler).
Time switch
Digital time switch
Day and week program, annual calendar
Automatic summer/winter time changeover
Automatic function for DHW heating and DHW circulation pump
Time, day and standard switching times for central heating, DHW
heating and the DHW circulation pump are factory-set
Switching times are individually programmable, i.e. up to four switch-
ing periods per day
Shortest switching interval: 10 minutes
Power backup: 5 years
Control units
(cont.)
56
VIESMANN
OIL/GAS BOILERS
11
5822 426 GB
